®  Slimline wheel cover manufacturer since 1982     HOME

¡@

One day all wheel cover will be made in this way

¡@

EurolinEÒ Slim line Color Box

¡@

EurolinE® Slimline package dimensions and container load capacity:

EurolinE® Slimline 4PCS a SET in a COLOR BOX (set of 4PCS)

13" 4pcs/set/box - 1 set in a color box/ 37.00x8.0x37.60cm / 0.40¡¦cf /1.80 Kgs.

14" 4pcs/set/box - 1 set in a color box/ 39.50x8.0x40.10cm / 0.45¡¦cf /2.00 Kgs.

15" 4pcs/set/box - 1 set in a color box/ 42.50x8.0x43.10cm / 0.52¡¦cf /2.05 Kgs.

16" 4pcs/set/box - 1 set in a color box/ 44.50x7.5x45.10cm / 0.53¡¦cf /2.80 Kgs.

¡@

EurolinE® Slimline 4PCS a SET in a COLOR BOX, 4 sets/boxes per Master carton

13" 4pcs/set/box - 4 sets per master carton 38.18x35.15x38.48cm / 1.82' cf / 6.20 Kgs.
14" 4pcs/set/box - 4 sets per master carton 41.21x37.57x41.51cm / 2.27' cf / 7.50 Kgs.
15" 4pcs/set/box - 4 sets per master carton 43.93x37.57x44.54cm / 2.60' cf / 8.50 Kgs.
16" 4pcs/set/box - 4 sets per master carton 45.75x31.51x46.36cm / 2.36' cf / 9.20 Kgs.

¡@

EurolinE® Slimline 4PCS a SET in a COLOR BOX, 5 sets/boxes per Master carton

13" 4pcs/set/box - 5 sets per master carton 16.34"X15.03"X15.15" / 2.16' cf /  7.50 Kgs.
14" 4pcs/set/box -
5 sets per master carton 16.34"X16.22"X16.34" / 2.51' cf /  9.00 Kgs.
15" 4pcs/set/box -
5 sets per master carton 16.34"X17.29"X17.41" / 2.85' cf / 10.25 Kgs.
 16" 4pcs/set/box -
5 sets per master carton 16.10"X18.01"X18.25" / 3.06' cf / 11.50 Kgs.

¡@

EurolinE® Slimline wheel cover container load:

1x20'ft 13" 2204~2223 sets. 1x40' 13" 4375~4412 sets. 1x40'HQ 13" 4885~4927 sets.

1x20'ft 14" 1792~1806 sets. 1x40' 14" 3557~3586 sets. 1x40'HQ 14" 3972~4004 sets.

1x20'ft 15" 1577~1590 sets. 1x40' 15" 3131~3156 sets. 1x40'HQ 15" 3496~3524 sets.

1x20'ft 16" 1720~1737 sets. 1x40' 16" 3415~3448 sets. 1x40'HQ 16" 3813~3850 sets.

¡@

SlimLine™ Installation

1. The last two numbers on your tire will indicate proper wheel cover size
(12",13",14", 15", 16" and 17"). See Fig. 1
Example: A tire with a size code of 15 inch uses a 15 inch wheel cover
2. Remove used wheel cover (hubcap) from wheel rim.
Ensure the mounting-clips are seated firmly
within the wheel cover blocks. See Fig. 2
3. Position the new wheel cover on wheel rim and guide the tire valve stem
through a slot in the wheel cover. Make sure all the wheel cover mounting-clips
(4 or 5 clips) fit over the wheel rim. See Fig. 3
4. Holding the wheel cover firmly in place, locate the mounting-clips of the wheel cover. Use the rubber mallet to tap the outer edge of the wheel cover mounting-clip until it is seated firmly against the wheel rim. See Fig. 4
5. Repeat step 4. for each wheel cover mounting-clip until all the mounting-clips are
seated firmly against the wheel rim.
6. Use the tack puller or the slotted screwdriver to pry free each mounting clip from the wheel rim. See Fig. 5

¡@

Traditional wheel cover  Spinner wheels/Hubcap Wheel Spinner

Steel Wheel-Replica  WireWheelCover  CapAds® Not Rotating Hubcap

¡@

22.5"HUBCAP
